@elrikpiro 17 February 2020 edited

Advanced BCH Monitoring with Tasker (Part 6: Bitcoin Cash SDK for tasker)

Previous part 5: Notifying price quotes on your phone https://read.cash/@elrikpiro/advanced-bch-monitoring-with-tasker-part-5-notifying-price-quotes-on-your-phone-dc674911 The Bitcoin Cash SDK for Tasker

As we saw in part 1, the main goal for all the interfaces and implementations we've been developing is to offer a common software development kit for tasker users to automatize their BCH-related routines and develop new ones. https://read.cash/@elrikpiro/advanced-bch-monitoring-with-tasker-part-1-refactoring-bd14f24e The configure call The goal of this call is to set the basic information the SDK needs to work on. entry: ( . . . ) function_configure: VariableSet(Name="%parameters", To="%par2"); VariableSplit(Name="%parameters", Splitter=";"); VariableSet(Name="%ADDRESSES", To="%parameters1"); VariableSet(Name="%CACHED_ADDRESSES", To="%ADDRESSES"); VariableSet(Name="%API_KEY", To="%parameters2"); VariableSet(Name="%CURRENCY", To="%parameters3"); Return(Value="SUCCESS", Stop="On"); function_loadBalance: ( . . . ) Step by step: Split the three semicolon-separated parameters into the `%parameters` Array Set the constants `%ADDRESSES`, `%API_KEY` and `%CURRENCY` Set the `%CACHED_ADDRESSES` constant with the `%ADDRESSES` value (we'll explain this later) Return when everything is done

Loading the balance data The goal is to load and return the current balance with a simple call. entry: ( . . . ) function_configure: ( . . . ) function_loadBalance: PerformTask(Name="BlockChairBlockExplorerAPI", Parameter1="function_load", Parameter2="%CACHED_ADDRESSES;%API_KEY", ReturnValue="%retval"); Return(Value="ERROR At TaskerBchSdk : %retval", If="%retval !~ SUCCESS"); PerformTask(Name="BlockChairBlockExplorerAPI", Parameter1="function_getTotalBalance", ReturnValue="%retval"); Return(Value="%retval", Stop="On"); function_loadCurrencyValue: ( . . . ) Step by step: Call the load function with the configured parameters Check if there was an error and stop the task if so Retrieve the total balance value Return that value to the caller

Load preferred currency quote The goal is to load the BCH - CURRENCY exchange ratio and return it to the caller. entry: ( . . . ) function_configure: ( . . . ) function_loadBalance: ( . . . ) function_loadCurrencyValue: PerformTask(Name="CoinGeckoExchangeAPI", Parameter1="function_load", ReturnValue="%retval"); Return(Value="ERROR At TaskerBchSdk : %retval", If="%retval !~ SUCCESS"); PerformTask(Name="CoinGeckoExchangeAPI", Parameter1="function_getTotalBalance", Parameter2="%CURRENCY", ReturnValue="%retval"); Return(Value="%retval", Stop="On"); function_computeCache: ( . . . ) Step by step: Call the load function with the configured parameters Check if there was an error and stop the task if so Retrieve the current currency exchange value Return that value to the caller

Computing the cache Our Addresses list can grow to be really long if we use many BIP39 wallets, usually having tons of addresses that do not contain any UTXO at all, we already created a function at the Block Explorer interface that gives us a list of addresses with funds and we are going to use it to update the `%CACHED_ADDRESSES` variables, effectively reducing the querying cost. https://read.cash/@elrikpiro/advanced-bch-monitoring-with-tasker-part-4-retrieving-your-data-from-the-block-explorer-api-29af674a entry: ( . . . ) function_configure: ( . . . ) function_loadBalance: ( . . . ) function_loadCurrencyValue: ( . . . ) function_computeCache: PerformTask(Name="BlockChairBlockExplorerAPI", Parameter1="function_load", Parameter2="%ADDRESSES;%API_KEY", ReturnValue="%retval"); Return(Value="ERROR At TaskerBchSdk : %retval", If="%retval !~ SUCCESS"); PerformTask(Name="BlockChairBlockExplorerAPI", Parameter1="function_getFundedAddresses", ReturnValue="%CACHED_ADDRESSES"); Return(Value="SUCCESS", Stop="On"); function_checkCache: ( . . . ) Step by step: We load all of our addresses (`%ADDRESSES`) on the block explorer Return if there's an error Compute the funded addresses and store it ( `%CACHED_ADDRESSES` ) Return

Checking if it's necessary to compute the cache There are several ways where the number of funded addresses could be rendered obsolete: When a transaction is performed on an unused address the cache won't catch it, as it's happening on one of the addresses that we are ignoring When one address that had funds spends all of them, going to zero balance To solve the first one we can schedule a periodic call to `computeCache` and to solve the second, one could be tempted to just remove the address, that would be ok in all cases where spending all funds implies sending them to another person, but actually the most common case is to have some change as a leftover and sending it to another address (usually dedicated for receiving change) in our wallet, that's why we would be checking, with the following function, if one of our addresses was depleted. entry: ( . . . ) function_configure: ( . . . ) function_loadBalance: ( . . . ) function_loadCurrencyValue: ( . . . ) function_computeCache: ( . . . ) function_checkCache: VariableSet(Name="%current_cache", To="%CACHED_ADDRESSES"); PerformTask(Name="BlockChairBlockExplorerAPI", Parameter1="function_getFundedAddresses", ReturnValue="%latest_cache"); VariableSplit(Name="%current_cache", Splitter=","); VariableSplit(Name="%latest_cache", Splitter=","); Return(Value="TRUE", Stop="On", If="%current_cache(#) eq %latest_cache(#)"); Return(Value="FALSE", Stop="On"); function_notifyChanges ( . . . ) Step by step: Copy the current cache and the latest list of funded addresses to local variables (`%current_cache` and `%latest_cache` respectively) Split both variables by comma Return TRUE if both arrays have the same length Return FALSE otherwise

Notifying function The goal is to get both balance and value and calling the notification service we made at part 5. The calling format will be `%balance;%value` https://read.cash/@elrikpiro/advanced-bch-monitoring-with-tasker-part-5-notifying-price-quotes-on-your-phone-dc674911 entry: ( . . . ) function_configure: ( . . . ) function_loadBalance: ( . . . ) function_loadCurrencyValue: ( . . . ) function_computeCache: ( . . . ) function_checkCache: ( . . . ) function_notifyChanges VariableSet(Name="%params", To="%par2"); VariableSplit(Name="%params", Splitter=";"); PerformTask(Name="PushNotificationGui", Parameter1="function_updateValue", Parameter2="%params2"); PerformTask(Name="PushNotificationGui", Parameter1="function_updateBalance", Parameter2="%params1"); PerformTask(Name="PushNotificationGui", Parameter1="function_notify"); Return(Value="SUCCESS", Stop="On"); Step by step: copy the parameters and split them by ";" Update the value an then the balance at the notification object, respectively notify the changes to the user Return

Use case example **Sdk_configure** This code will prompt you to input the addresses you are going to use, the currency and the API key if applicable. This is meant to be used whenever you want to change one of these settings, but at least once before start using this SDK. VariableQuery(Title="input addresses", Variable="%addresses"); VariableQuery(Title="input api key (if any)", Variable="%api_key"); VariableQuery(Title="input currency", Variable="%currency", Default="usd"); PerformTask(Name="TaskerBchSdk", Parameter1="function_configure", Parameter2="%addresses;%api_key;%currency"); **Sdk_routine** This code will load the balance, load the currency quotes, notify the changes and update the cache if necessary, this code is meant to be used as a periodic task (i.e: every thirty minutes) PerformTask(Name="TaskerBchSdk", Parameter1="function_loadBalance", ReturnValue="%balance"); Popup(Title="ERROR", Text="%balance", If="%balance ~ ERROR"); PerformTask(Name="TaskerBchSdk", Parameter1="function_loadCurrencyValue", ReturnValue="%value"); Popup(Title="ERROR", Text="%value", If="%value ~ ERROR"); PerformTask(Name="TaskerBchSdk", Parameter1="function_notify", Parameter2="%balance;%value"); PerformTask(Name="TaskerBchSdk", Parameter1="function_checkCache", ReturnValue="%retval"); If("%retval ~ FALSE"); PerformTask(Name="TaskerBchSdk", Parameter1="function_computeCache", ReturnValue="%retval"); Popup(Title="ERROR", Text="%retval", If="%retval ~ ERROR"); EndIf(); **Sdk_cache** Finally, This code will refresh the cache, this code is meant to be used once a day, to avoid orphan addresses with funds. PerformTask(Name="TaskerBchSdk", Parameter1="function_computeCache", ReturnValue="%retval"); Popup(Title="ERROR", Text="%retval", If="%retval ~ ERROR"); "Dude, I pass on implementing this here... Where can I download it?" You can access the Sdk on this link. (You need to have tasker installed) or download the import XML directly from Github. https://taskernet.com/shares/?user=AS35m8kIBt7YDTyExrs93%2BepaSFltAx90KDg%2FEJ4WmANtc0PAvKb3JlbMqJgBA5RZ3ydCfijigTPWdo%3D&id=Project%3ABCH-Monitor https://github.com/ElrikPiro/taskerBchSdk/tree/master [sponsors]

https://blockchair.com/ *Special thanks to* *Blockchair.com* *for providing the API key* *Don't forget to subscribe, feedback will be appreciated!* Expect future updates! Requests are accepted at comments.
